3D measurement of blisters

Engineering service

Task Dimension checking of 3 different kinds of thermo formed product trays to find root case of handling difficulties. Solution With the aid of a scanning fixture and automated measurement application we created measurement reports for each tray. Every tray has about...

Adjustable discharge belt stand

Custom machines, Engineering service

Task Creating an adjustable stand that fits to the press and provides height adjustability for the existing discharge belts. Solution 500 t press discharge area was measured, and a simple pneumatic wrench driven parallel spindle pair was installed on the columns of...

Bending Machine Maintenance

Custom machines, Engineering service

Task Stopper of two similar worn-out bending machines had to be maintained. Solution Stopper was redesigned and was equipped with a position indicator to make product change easier and to avoid product...

Gun barrel measurements

Engineering service

Task Measure complex geometry of a gun barrel and create drawing in order to provide information for fixture design. Solution We scanned the section in consideration with a hand-held Freescan Combo metrology scanner. Cleaned the mesh, exported stl. From the mesh data...

1000 bar pump

Custom machines, Engineering service

Task Adopt high pressure low volume pumps to specification. Solution Based on the given sample we simplified the design of the pump, decreased its total length and cut manufacturing costs while performance remained the same. We manufactured 3 pieces from this item for...

Lollipop

Engineering service

Task Demaged ball joint repair. Solution A damaged 3-piece ball joint was dismounted from a 35 t press. Parts were scanned, original actual geometry was measured by a laser scanner. Alignment errors were analyzed in 3D models revere engineered from point clouds. We...
